Soft Magnetic Nanocrystalline Core/ Nanocrystalline alloy core 25x40x15

Jul 28, 2016

Leave a message

Basic Info.

Nanocrystalline core characteristics

The grain size of the nanocrystalline alloy is smaller than that of the magnetic exchange interaction length, which leads to the average magnetic crystal anisotropy is very small.

Material characteristics

Model	P/N	Strip width（mm）		Strip thickness（μm)
		size	tolerance	size	tolerance
1K101	YTA	2-80mm	±（0.1~0.3）	0.02~0.04	±0.002
	YTB
1K107	YTA	2-80mm	±（0.1~0.3）	0.02~0.04	±0.002
	YTB
	YTC
	YTD

Product Description

High frequency low loss

Rapid quenching soft magnetism crystalline alloy

Made of Fe-based amorphous soft magnetic material

High saturation magnetic flux density

Wide range of constant

Low loss at high frequency

Low leakage magnetic pole

Excellent temperature characteristics

Available in various size

High ui , initial permeability

High precision

High Linearity

Accuracy range : 0.5~ 0.05 class

High cost performance

Working temperature : -55 ~ 130 ℃

Performance index comparasion between Nanocrystalline and permalloy core

Basic magnetic parameters	Nanocrystalline	permalloy
Saturation magnetic induction strengthBS (T)	1.20	0.70
initial permeability（GS/Oe）	50000～100000	50000～100000
MAX initial permeability（GS/Oe）	>300000	>200000
Coercive force（A/m）	<1.6	<0.8
density（g/cm3）	7.25	8.8
filling factor	>0.70	>0.88
