PCB Current Sense Transformer

Providing with quality and standard customer-made electronic and passive components pcb current sense transformer and solution products, Fullstar Electronics is a leading pcb current sense transformer manufacturer and supplier in China. welcome to wholesale electronics pcb current sense transformer from our factory.

A PCB Current Sense Transformer is an electronic component specifically designed for printed circuit board mounting. Its primary function is to measure AC current with high precision in a non-contact manner. It proportionally converts a larger AC current flowing through a conductor into a smaller current signal, which is easy for subsequent circuits to monitor and control.

In simple terms, its core role is to "monitor" current without consuming almost any power.

SHAANXI FULLSTAR ELECTRONICS CO.,LTD is specialized in electronics and magnetic components .
The main products are: High-precision current sensing transformer, PCB High- frequency current transformer, SMD high frequency current sensing transformer, Zero phase current transformer, Toroidal current transformer, Split-core current transformer, etc.,

Our factory has 30 years' experience in electronics field and the annual volume is above 200,000,000 pieces. We are ISO9001:2015 certified company.

✨ Core Advantages and Features

Compared to other current sensing methods (like using a shunt resistor), PCB current transformers offer several distinct advantages:

Extremely Low Insertion Loss: They don't rely on creating a voltage drop to measure current, so they consume negligible power. This makes them ideal for high-efficiency applications, especially those involving large currents.

Inherent Electrical Isolation: There is no direct electrical connection between the primary (power side) and secondary (control/measurement side). This effectively protects sensitive low-voltage control circuits from high-voltage transients, enhancing system safety.

Excellent Accuracy: By carefully selecting the turns ratio and the burden resistor, a high degree of measurement accuracy can be achieved.

Easily Adjustable Signal: The ability to scale the current signal simply by changing the burden resistor offers great design flexibility.

Suitable for High-Frequency Applications: They are particularly adept at measuring high-frequency AC or pulsed currents found in switching power supplies, typically ranging from tens of kHz to over 1 MHz.

Of course, there are some limitations to consider:

Primarily for AC Measurement: Standard models cannot measure pure DC current.

Occupies PCB Space: They are physically larger compared to tiny components like shunt resistors.

Relatively Higher Cost: They are generally more expensive than discrete components like resistors.
