EE28 High Frequency Transformer Flyback Transformer
2.Sample testing support.
3.Can be returned if there is any quality problem.
4.100% guaramtee quality.
Description
Technical Parameters
EE28 High Frequency Transformer Flyback Transformer SMPS Core Type Transformer
1.EE28 High Frequency Transformer Flyback Transformer SMPS Core Type Transformer introduction
High frequency transformer is the most important part of switching power supply. There are many topologies in switching power supply. For example, half-bridge power conversion circuit, when two switch transistors turn on in turn to generate 100 kHz high-frequency pulse wave, then through the high-frequency transformer for voltage conversion, output AC,high-frequency transformer winding coil turns ratio determines the number of output voltage.
2.product Parameter
Material | Copper Wire + Ferrite Core |
Quality | 100% Tested |
Frequency | 1KHz -200KHz |
Application | home security system |
3.Product feature
1 Operating frequency: 20kHz-500KHz
2 Output power: 30 to 80 W
3 Operating temperature:-40 ℃ to +125 ℃
4 Storage temperature:-25 ℃ to +85 ℃
5 Customized designs are available
4.Product application
The advantage of planar transformer it ites low height,which makes it possible to set more turns on the core. A high power density converter needs a small magnetic element,and the planar transformer satisfies this requirement well.
Our factory
SHAANXI FULLSTAR ELECTRONICS CO.,LTD is specialized in electronics and magnetic components. We are professional Electronics manufacturing company with good reputation in the field. Our company keeps pace with update technologies and developing its capacity. As an ISO certified company we adhere to strict quality control system thus all products to meet RoHS Standard and industry international standards.
Fullstar electronics are always ready to provide customers with the best products and services. Sincerely look forward to establishing long term cooperation with you to create the brilliancy together.
Ecperienced Workers
Our Team
We own an outstanding sale and service team and establish a huge marketing network covering market both home and aboard.
Our operating policy is "Quality comes first, customer foremost".
Exhibition And Customer Visit
We serve a lot of customers abroad and establish a stable supply relationship in our cooperation.
They visit us to show their projects.Some of them vist us annually for mutual supports.
5.Certificate
6.FAQ
Q: What service your company can offer?
A: Products design, development, production, test as per requirement.
Q: Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
Q: What is your terms of packing?
A:Generally, we pack our current transformer in General cartons.
